Lan only system – Grass Valley JEP-100 v.1.2.0 User Manual
Page 36
34
JEP-100 — Installation and Operating Manual
Section 1 — JEP-100 Control Panel
LAN Only System
In this system, the JEP is operated in Ethernet mode, where the LAN con-
nection is used both for operation and for software upgrade purposes. See
Figure 12.
Figure 12. LAN only system naming and addresssing
100baseT Jupi-
ter LAN
IP switch
Panel ID
“02”
Panel ID
“01”
64 JEP!100s per
CM maximum
Panel ID
“64”
Jupiter
File Server
CM!4000 System Controller
“CM1”
“JEP1”
“JEP2”
“JEP64”
8536_18
