Power supply specifications
The FT server power supply specifications are shown in the table below:
Table 2: Power specifications
Type II Specifications Type I Specifications Power Supply
AC 100V-240V +/- 10%, 50/60Hz +/-
3Hz AC 100V-240V +/- 10%, 50/60Hz +/-
3Hz Type
1300VA, 1290W 1400VA, 1390W Power
Consumption
Environmental specifications
The FT server specifications are shown in the following table:
Type I and Type II Specification Characteristic
-10° to +55° C Ambient Temperature Non-operating
20 to 80% RH (non-condensing) Ambient Humidity Non-operating
+10° to +35° C Ambient Temperature Operating
20 to 80% RH (non-condensing) Ambient Humidity Operating
