Switchback choices Maintain Stability
Maintain Primary,
Maintain Stability, or
Manual.
Output Control/
Switching Strategy
Switchback
Maintain Primary, Maintain Stability or Man-
ual radio button
SwBckStrgy
Switchback delay (applies to
Maintain Primary only)
4 sec 0 to 254 sec
Output Control/
Switching Strategy
Maintain Primary Delay (Sec)
SwBckDel
Select inputs for output pair 1.1 (J1)
and 1.2 (J3)
Program
Program,
Backup,
Primary, Input,
Secondary Input,
or Alternate Input.
Output Control/
Programmable Outputs Selection
Input for Output Pairs 1.1 and 1.2
Input pulldown
OutSel1
Select inputs for output pair 2.1 (J2)
and 2.2 (J4)
Program
Program,
Backup,
Primary, Input,
Secondary Input,
or Alternate Input.
Output Control/
Programmable Outputs Selection
Input for Output Pairs 2.1 and 2.2
Input pulldown
OutSel2
Select inputs for output pair 3.1 (J6)
and 3.2 (J8)
Program
Program,
Backup,
Primary, Input,
Secondary Input,
or Alternate Input.
Output Control/
Programmable Outputs Selection
Input for Output Pairs 3.1 and 3.2
Input pulldown
Outsel3
Recall factory default parameters N/A See Defaults column
User Settings/
Recall Factory Defaults
Set Factory Defaults button
N/A
Recall factory names N/A
See I/O Config web
page
User Settings/
Recall Factory Defaults
Set Factory Names button
N/A
Table 12. Summary of 8972PX Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Newton
Control
Panel
