76 8972PX — Instruction Manual
Warnings and Alarm Summary Tables
Warnings and Alarm Summary Tables
Table 10 describes the different type of warnings and alarms that may occur
on the 8972PX module. The SNMP Trap Index column shows the trap index
number used in conjunction with
Table 11 on page 77 .
Table 11 on page 77 gives detailed information on the SNMP Trap Index for
use with an SNMP application such as NetCentral.
Table 10. List of Warnings and Alarms
Alarm Type Web Page Description
FAULT
LED
State
Comments
SNMP Trap
Index
Fault Firmware failure On Firmware configuration failure 1
Fault
Firmware DCM not locked
On
Firmware Internal Clock manager
failure
2
Fault
Bad Firmware image
On
A Wrong Firmware Image has been
downloaded
3
Fault Power Supply failure On 4
Warning For future use 5
Warning
Wrong Rear Module (incompatible with
8972PX)
Flash 6
Warning Primary Input Signal Not Detected Flash 7
Warning Primary Input is Invalid or the Wrong Format Flash 8
Warning Primary SD Input Has No EDH Inserted Flash 9
Warning Secondary Input Signal Not Detected Flash 10
Warning
Secondary Input is Invalid or the Wrong For-
mat
Flash 11
Warning Secondary SD Input Has No EDH Inserted Flash 12
Warning Alternate Input Signal Not Detected Flash 13
Warning Alternate Input is Invalid or the Wrong Format Flash 14
Warning Alternate Input Has No EDH Inserted Flash 15
Informational GPI is controlling the Input Signal Switch N/A
This prevents all switch actions from
web page/Newton C/P/local control
16
