8972PX — Instruction Manual
49
Configuration
Status Web Page
Use
this
link
) reports the status of, and infor-
mation about, the front media and rear modules in both graphical (using
color to indicate status) and textual formats. It also reports the status of the
input video signals to the module, and the Frame Bus status. Video and ref-
erence signal reporting can be enabled and disabled to the module level on
the I/O Config web page.
In general, graphics and text colors used for status indication are the fol-
lowing:
•
Green = Pass – signal or reference present, no problems detected.
•
Red = Fault – fault condition.
•
Yellow = Warning – signal is absent, has errors, or is mis-configured.
•
Gray = Not monitored.
Note
Always refresh the page first with the Refresh button at the top of the page
(shown at left) to update the current status of the web page.
Web Page Header
The web page header for the 8972PX module is described in detail in
.
Module Physical Structure
Status is reported for the front and rear modules in the Module Physical
Structure graphic as follows:
•
Rear Module – the presence, name, and status of the rear module is
reported in the graphic on the left. If the rear module is the wrong type
or missing, the graphic will indicate the status by color and text within
the graphic.
•
Front Processing Module – the presence, name, and status of the front
processing module is reported in the graphic on the right. The graphic
will indicate the status of the front module by color and text within the
graphic.
