8972PX — Instruction Manual 83
Appendix
Configuration Summary Table
Table 12 provides a complete summary of the 8972PX module functions
and a comparison of the functionality available with each control type
along with the ranges and default values for each parameter and notes on
each control.
Table 12. Summary of 8972PX Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Newton
Control
Panel
Enable Primary input status reporting Enable Enable or Disable
I/O Config
Primary Input Reporting checkbox
N/A
Enable Secondary input status report-
ing
Enable Enable or Disable
I/O Config
Secondary Input Reporting checkbox
N/A
Enable Alternate input reporting Enable Enable or Disable
I/O Config
Alternate Input Reporting checkbox
N/A
Input standard selection Auto
Auto,
DVB/ASI,
HD 1080i 59.94,
HD 720p 59.94,
HD 1080i 50,
HD 720p 50,
SD 480i 59.94,
or SD 576i 50.
System Config/
Input Standard Selection
Input Standard pulldown PrgOutStd
Set Bypass Mode
Active Processing
Enabled
Passive Bypass Only or
Active Processing
Enabled
System Config/
Bypass Mode
Bypass Mode Control
Passive Bypass Only or Active Processing
Enabled radio button
N/A
Use Alternate input in Autonomous
mode
Disable Enable or Disable
System Config/
Alternate Input Usage In Autonomous Switch
Mode
Use Alternate Input
Enable or Disable radio buttons
UseAltIn
Set DVB/ASI packet length 188 188 or 204
System Config/
DVB/ASI Packet Length
Packet Length (in bytes)
188 or 204 radio button
N/A
Enable EDH/CRC error detection for
HD/SD criteria
Disable Enable or Disable
HD/SD Criteria
Valid Signal Criteria
EDH/CRC Errors Enable checkbox
EDHCRCEn
Set EDH/CRC threshold value for error
fields before switching
4
1, 2, 4, 6, 8, 16, 24, 32,
64, 96, 128, 192, 256,
512, 768, 1024
HD/SD Criteria
EDH/CRC Errors
EDH/CRC Error Threshold
Error Fields pulldown
FldErrThrd
Set EDH/CRC threshold value for error
fields before switching 4 Error Fields
16 Total Fields
1, 2, 4, 6, 8, 16, 24, 32,
64, 96, 128, 192, 256,
512, 768, 1024
HD/SD Criteria
EDH/CRC Errors
EDH/CRC Error Threshold
Total Fields pulldown
NumFldThrd
