8972PX — Instruction Manual 27
Configuration Summary
Figure 5. Module in Passive Bypass Mode
8580_04r1
GPI I/O
J10: Secondary Input
J9: Primary Input
J7: Program Output
Relay Protected Program Output
Primary and Secondary
signals bypass the
front module
