55
Tx power:N/A
Rx power:N/A
Port 9
Temperature:64.00 C
Tx power:-6.0 dBm
Rx power:-30.0 dBm
Port 10
Temperature:67.00 C
Tx power:-6.0 dBm
Rx power:-2.0 dBm
Note: Administrative Status -> Port state of the port.
Operating status -> Current status of the port. Duplex
-> Duplex mode of the port. Speed -> Speed mode of the
port. Flow control -> Flow Control status of the port.
Rate Control
Rate
Control –
Ingress or
Egress
Switch(config-if)# rate-limit
egress Outgoing packets
ingress Incoming packets
Note: To enable rate control, you should select the
Ingress or Egress rule first; then assign the packet type
and bandwidth.
Rate
Control –
Filter
Packet Type
Switch(config-if)# rate-limit ingress mode
all Limit all frames
broadcast Limit Broadcast frames
flooded-unicast Limit Broadcast, Multicast and
flooded unicast frames
multicast Limit Broadcast and Multicast frames
Switch(config-if)# rate-limit ingress mode broadcast
Set the ingress limit mode broadcast ok.
Rate
Control –
Bandwidth
Switch(config-if)# rate-limit ingress bandwidth
<0-100> Limit in magabits per second (0 is no limit)
Switch(config-if)# rate-limit ingress bandwidth 8
Set the ingress rate limit 8Mbps for Port 1.
Storm Control
Strom Switch(config-if)# storm-control
