97
VLAN ID: ID of the VLAN.
Name: Name of the VLAN.
Status: Static shows this is a manually configured static VLAN. Unused means this
VLAN is created by UI/CLI and has no member ports. This VLAN is not workable
yet. Dynamic means this VLAN is learnt by GVRP.
After created the VLAN, the status of this VLAN will remain in Unused status until
you add ports to the VLAN.
4.6.5 CLI Commands of the VLAN
Command Lines of the VLAN port configuration, VLAN configuration and VLAN
table display
Feature Command Line
VLAN Port Configuration
Port Interface
Configuration Switch# conf ter
Switch(config)# interface fa5
Switch(config-if)#
VLAN Port PVID Switch(config-if)# switchport trunk native vlan 2
Set port default vlan id to 2 success
QinQ Tunnel Mode Switch(config-if)# switchport dot1q-tunnel
mode Set the interface as an IEEE 802.1Q tunnel
mode
Switch(config-if)# switchport dot1q-tunnel mode
