48
TASCAM X-48MKII
Final Mix
It is possible to complete your project entirely inside the
X-48MKII. You can add EQ and compression and automate
channel levels during mixdown. You will still need a
master recorder to monitor and capture the final mix, like
the TASCAM DV-RA1000HD.
To mix on the X-48MKII:
1 Click the Output field on the Master channel on the
right side of this window. This opens a menu of
options. Mouse over the Stereo Outputs submenu
and choose SPDIF.
2 Make sure that the Mix button is on/green for any
tracks/channels you want to go to the Master out.
3 Connect the S/PDIF digital out to the S/PDIF digital
in on your D/A converter or recorder. Change the
on-screen mixer channels and DSP settings to mix
your project.
7 – Mixer
