TASCAM X-48MKII
41
Track Key Punch
The X-48MKII can be set to enter record mode without any
tracks armed. Recording will then begin on any channel
whose track-arming button is pressed.
In other words, even when all track record arming buttons
are off, you can press the transport REC and PLAY buttons
to start recording mode. Then, recording will start when
you press a track record arming button.
To enable this function:
Mouse/Keyboard Operation
1 Click the Windows menu and select the Settings
window.
2 Select the Transport tab. Check the box labeled Track
Key Punch.
Front Panel Operation
1 Press the PREF button. Press the
5
/
b
buttons to
select
Track Key Punch
and press CHNG.
2 Select either
Off
or
On
using the
5
/
b
buttons
and press Enter.
Recording time
Sampling
frequencies
Quantization rates
Built-in HDD data volume 960 GB Per 100 GB of external drive capacity
48 track 24 track 48 track 24 track
44.1 kHz
16 bit 60 hr 33 min 121 hr 7 min 6 hr 33 min 13 hr 07 min
24 bit 40 hr 22 min 80 hr 44 min 4 hr 22 min 8 hr 44 min
32 bit floating 30 hr 16 min 60 hr 33 min 3 hr 16 min 6 hr 33 min
48 kHz
16 bit 55 hr 37 min 111 hr 16 min 6 hr 01 min 12 hr 03 min
24 bit 37 hr 05 min 74 hr 11 min 4 hr 01 min 8 hr 02 min
32 bit floating 27 hr 49 min 55 hr 38 min 3 hr 00 min 6 hr 01 min
88.2 kHz
16 bit 30 hr 16 min 60 hr 33 min 3 hr 16 min 6 hr 33 min
24 bit 20 hr 11 min 40 hr 22 min 2 hr 11 min 4 hr 22 min
32 bit floating 15 hr 08 min 30 hr 16 min 1 hr 38 min 3 hr 16 min
96 kHz
16 bit 27 hr 49 min 55 hr 37 min 3 hr 00 min 6 hr 01 min
24 bit 18 hr 32 min 37 hr 05 min 2 hr 00 min 4 hr 01 min
32 bit floating 13 hr 54 min 27 hr 48 min 1 hr 30 min 3 hr 00 min
The above recording times are estimates. Actual times will vary depending on the effective data capacity of a drive, the •
number of projects and other factors.
The built-in hard disk data volume capacity is the built-in hard disk less the space taken by the system volume.
•
