Printer Commands Chapter 5
5-8 438 Operator’s Manual - 880052-0100
0 = Send >INPUT 1< active HIGH
3
Response After Print: If enabled, an enquiry response will be sent
through the communications after every print automatically.
1 = Enable
0 = Disable
4
INPUT 2 Active State: This bit determines whether the INPUT 2 sensor
must see an object or not to send back the >INPUT 2< response. A
setting of 1 (active LOW) will report the >INPUT 2< message if no
reflection is detected. A setting of 0 (active HIGH) will report the
>INPUT 2< message if a reflection is detected.
1 = Send >INPUT 2< active LOW
0 = Send >INPUT 2< active HIGH
5 Accept “|” for Ctrl: Sets whether the “pipe” character will be
interpreted the same as the “Ctrl” key. The “pipe” character is the
+ \ key.
1 = Disable
0 = Enable (<|> key functions as key)
6
Accept “^” for Ctrl: Sets whether the “caret” character will be
interpreted the same as the “Ctrl” key. The “caret” character is the
+ 6 key.
1 = Disable
0 = Enable (^ key functions as key)
7
Binary Compression: If enabled, the printer will accept downloaded
binary compressed font and/or graphic files. The ^E command will not
function. (See 5.1)
1 = Enable Binary Mode
0 = Disable Binary Mode
8
Detect Black Line on Power-up: If enabled, the printer automatically
feeds labels on Power-up to determine the proper ^D90 value.
1 = Enable
0 = Disable
5.2.1.4
Software Switch #4
^AB ^D
COMMAND
XX 24 Change SW4: Software Switch #4.
^AB12345678 (each bit is represented by a numeric position number)
Position:
1 Slashed Zeros: If enabled, the printer will print a slash through the
embedded zero (“0”) characters.
1 = Enable
0 = Disable
