Page 39
Designing Labels Using LDS
Chapter 4
4-14
438 Operator’s Manual - 880052-0100
4.6.6.1
Embedded Fonts
The Model 224 and 424 printers provide seven resident Helvetica style embedded fonts that
can be selected using the CGN when text is selected by the appropriate TCI value.
Embedded Bitmapped Fonts
CGN
VALUE
POINT
SIZE
FONT TYPE
FONT SAMPLE
1
6
Swiss™721 Bold
6pt ABCDEFGHIJKLMNOPQRSTUVWXYZ1234567890
2
8
Swiss™721 Normal
8pt ABCDEFGHIJKLMNOPQRSTUVWXYZ1234567890
3
10
Swiss™721 Normal
10pt ABCDEFGHIJKLMNOPQRSTUVWXYZ
4
12
Swiss™721 Normal
12pt ABCDEFGHIJKLMNOPQRSTU
5
14
Swiss™721 Normal
14pt ABCDEFGHIJKLMNOPQR
7
12
OCR-A
ABCDEFGHIJKLMNOPQRSTUVWXYZ
8
12
OCR-B
ABCDEFGHIJKLMNOPQRSTUVWXYZ
Table 4-5
CGN—Embedded Fonts
4.6.6.2
Downloadable Fonts and Graphics
When selecting downloadable fonts and graphics using TCI value of “7” or “8”, the CGN
denotes the memory slot (1-255) where the font or graphic has been stored. See Chapters
6 and 7 for additional information regarding downloadable fonts and graphics.
For example: If a graphic had been stored into RAM (volatile) memory slot 1 (see Chapter 5
for additional information), the proper TCI would be “8” and the CGN value would be “1”.
Standard Downloadable Font Set
CGN
VALUE
POINT
SIZE
FONT TYPE
10
6
Swiss™721 Normal 0 degree
11
6
Swiss™721 Normal 90 degree
12
8
Swiss™721 Normal 0 degree
13
8
Swiss™721 Normal 90 degree
14
10
Swiss™721 Normal 0 degree
15
10
Swiss™721 Normal 90 degree
16
12
Swiss™721 Normal 0 degree
17
12
Swiss™721 Normal 90 degree
18
14
Swiss™721 Normal 0 degree
19
14
Swiss™721 Normal 90 degree
20
16
Swiss™721 Normal 0 degree
