PROCESS REFRACTOMETER PR-21-S-LPH
Model and Description Model
PR-21-S = Sensor PR-21-S
Refractive Index range limits
50= Low range R.I. 1.320....1.460 max. span R.I = 0.13
50
57= High range R.I. 1.380....1.530 max. span R.I = 0.12 57
Process connection
-L = Sandvik L-clamp, 88 mm
-L
Sensor wetted parts material
XS = SAF 2205 / AISI 316L
XS
Electrical classification
-GP = General purpose
-GP
Sensor length
-LPH = Retractable long probe
-LPH
Prism wash
-YPY = Without integral nozzle mounting connection
-YPY
Parts for off-line calibration check and instrument verification
Model and Description Part No.
PR-5002 = Sample holder PR-5002
PR-2000 = R.I. liquid set 12 x 1/4 fl.oz. (7 cc)
Including R.I. liquids: 1,33; 1,35; 1,36; 1,37; 1,39; 1,41; 1,43; 1,45; 1,46; 1,47; 1.49; 1.50
PR-2000
Figure 1.6 Model code of PR-21-S-LPH
PRELIMINARY
PRICE LIST PR-21-S 3(2)
Area: EURO
Currency: EURO
Effective: June 17th , 2013
Replaces:
K-PATENTS OY  Postal Address: P.O.Box 77, FI-01511 Vantaa, Finland  Street Address: Elannontie 5, FI-01510 Vantaa, Finland
Tel.int.+358 207 291 570 Fax int.+358 207 291 577  [email protected]  www.kpatents.com  Vat No. FI03035575
Business ID 0303557-5  Registered in Helsinki
Mounting Hardware for Intrinsically Safe –IA Sensor
Description Part no
PR-10910 = IS Isolator ( MTL 5053 Isolator/Power Supply) PR-10910
Enclosure Option
-PCE = Polycarbonate enclosure with DIN-rail -PCE
Part Number and Description Part No.
PR-8260 = Interconnecting cable between isolator and sensor ( I.S. blue cable) PR-8260
Cable length
-010 = 10 meters (33 feet), standard length
-010
- _ _ _ = Specify cable length in meters with 10 meters increments.
Maximum length is 200 meters (660 feet)
-_ _ _
Description Part no
PR-8250 = Power supply cable between Indicating Transmitter and Isolator PR-8250
Cable length
-010 = 10 meters (33 feet), standard length -010
- _ _ _ = Specify cable length in meters with 10 meters increments.
Maximum length is 100 meters (330 feet)
-_ _ _
Figure 1.7 Model code of PR-21-S-...-IA
