4 PR-21-S instruction manual
1.1.1 Model code
PRELIMINARY
PRICE LIST PR-21-S 1(2)
Area: EURO
Currency: EURO
Effective: June 17th , 2013
Replaces:
K-PATENTS OY  Postal Address: P.O.Box 77, FI-01511 Vantaa, Finland  Street Address: Elannontie 5, FI-01510 Vantaa, Finland
Tel.int.+358 207 291 570 Fax int.+358 207 291 577  [email protected]  www.kpatents.com  Vat No. FI03035575
Business ID 0303557-5  Registered in Helsinki
K-PATENTS DIGITAL PROCESS REFRACTOMETER PR-21-S
A heavy-duty industrial process refractometer model for measuring the liquid
concentration of a wide range of chemicals and other liquid phase mediums. Sensor is
suitable for process pipe installation and also for tank and reactor installations.
Model and Description Model
PR-21-S = Sensor PR-21-S
Refractive Index range limits
50= Low range R.I. 1.320....1.460 50
57= High range R.I. 1.380....1.530 57
Process connection
-L = Sandvik L-clamp, 88 mm -L
-D = DIN-flange 2656, PN 25, DN 80 -D
-A = ANSI-flange 150 psi, 3 inch -A
-J = JIS-flange , 10K 80 A -J
Sensor wetted parts material
SS = AISI 316 L SS
XS = AISI 316 L / SAF2205 XS
Electrical classification
-GP = General purpose -GP
-FM = FM Class I, Div.2, Groups A,B,C & D, T6 -FM
-IA = ATEX and IECEx certified EX II 1 G Ex ia II C T4 Ga (up to Zone 0) -IA
Sensor length
-STD = Standard -STD
-LPL = Long probe, insertion length 302mm -LPL
-LPS = Long probe, insertion length 150mm -LPS
Prism wash
-HPY = Integral nozzle mounting connection -HPY
-HPN = Integral nozzle for water -HPN
-HPS = Integral nozzle for steam -HPS
-HPX = Integral nozzle for water, drawing number DIM-310/ASAHI -HPX
-YPY = Without integral nozzle mounting connection -YPY
(A) Leave this section blank, code is specified by the Manufacturer
according to the Ordering Information Sheet
Model and Description Drawing No. Model
DTR = Indicating Transmitter (connectivity for two sensors) DIM-417 DTR
STR = Indicating Transmitter (connectivity for one –IA sensor) DIM-417 STR
Cable connection
-U = ½ inch NPT-type conduit hubs -U
-M = M20x1,5 metric cable glands -M
Electrical classification
- GP = General purpose -GP
Transmitter options (B) (leave this section blank, if AC supply is specified)
-DC = Power supply 24 V DC -DC
(B) Note standard power supply is 100-240 VAC 50/60 Hz
Part Number and Description Part No.
PR-8230 = Interconnecting cable between transmitter and sensor ( standard black cable)
( for STR transmitter: Interconnecting cable between transmitter and isolator)
PR-8230
Cable length
-010 = 10 meters (33 feet), standard length -010
- _ _ _ = Specify cable length in meters with 10 meters increments.
Maximum length is 200 meters (660 feet)
-_ _ _
PR-8031 Connector for cable with screw terminals PR-8031
All prices are FCA, Helsinki-Vantaa Airport, Finland. Delivery times are 12 weeks A.R.O. for standard instruments
Fill in the Ordering Information Sheet (OIS-PR-21) for each instrument
Figure 1.5 Model code of PR-21-S
