4-96

PRE-INSTALLATION

HT4001

Instruction Manual

3-13

Power Requirements

The customer must provide the power cable for the water-muffler pump. The pumps provided by Hypertherm take a
three-phase input. Part numbers and corresponding voltages are listed below. Input current information is provided
on the motor data plate. Present pump systems all draw less than 20 amps. Select cable sizes accordingly.

Water Muffler System

Water Pump

Part Number

Part Number

Input Voltages

034126 (w/hoses)

028042

230-460 Volt/3Ø/60 Hz

034128 (w/hoses)

028299

380-415 Volt/3Ø/50 Hz

034130 (w/hoses)

028308

575 Volt/3Ø/60 Hz

034127 (wo/hoses)

028042

230-460 Volt/3Ø/60 Hz

034129 (wo/hoses)

028299

380-415 Volt/3Ø/50 Hz

034131 (wo/hoses)

028308

575 Volt/3Ø/60 Hz

Air Requirements

Provide a clean, dry, oil-free source of air with a delivery pressure between 80 and 120 psi (5.5 and 8.3 bar) with a
minimum flow rate of 20 scfm.

For further information, please refer to Hypertherm water muffler instruction manual (801730).

Initial Height Sensing (IHS)

The customer must provide a source of compressed air to the Initial Height Sensing system.

Air Requirements

Use a clean, dry, oil-free source of air to prevent possible problems created by moisture and water in the line.
Reduce shop air pressure to 20 psi (1.4 bar) with a regulator. Use a 1/4 inch I.D. hose between the regulator and
the inductive height control module.

An option to the IHS system is an upper-limit switch and cable. Please refer to Initial Height Sensing Connections
in the Installation section of this manual for further information.
