PARTS LIST
6-96
HT4001
Instruction Manual 7-19
Remote High Frequency Console (077010)
Part
Item Number Description Designator Qty.
077010 HT4001 RHF Console
1 001466 Encl: HT4001 RHF CSL 1
2 004078 Shld Adptr:200/400/500/HD1070 1
3 005100 Switch, Door Interlock S1, S2 2
4 008082 Bshg: 1/2 ID X 5/8 Hole 3
5 008212 Strainrlf: 1/2NPT X .197-.354 1
6 008482 Strainrlf, 1-1/4 NPS Basket 2
7 008643 Locknut, 1/2" NPT 1
8 015001 Adapter, Bulkhead, 1/4 NPTF 2
9 015012 Adapter, 1/4 NPT X #6 3
10 024040 Hose Assy, #4 X 12" 1
11 024111 Hose Assy, #6 X 13" 1
12 024256 Hose Assy, #6 X 6-1/2" 1
13 027014 Lockwasher, 1-3/4" internal star 1
029641 Neg Bus SA 1
14 002135 Pnl: Neg Bus 1
15 004074 Blk: 200/400/500 Cath Neg Bus 1
16 009224 Cap, Pol .22 µF 1000 WVDC 10% 1
129041 Hi Frequency Panel SA
17 009040 Filter, AC, 3 Amp 3WI FL1 1
18 009246 Cap, Poly-Paper .5µF 2500V C4A 1
19 009246 Cap, Poly-Paper .5µF 2500V C4B 1
20 009320 Inductor, Hi Freq Coil T2 1
009350 Spark Gap Assy SG1 1
21 004144 Bar:009350 Spk Gap Cap Mtg 1
22 004061 Electd: Spk Gap 1/8 X 1.6 3
23 004140 Base:40/100/200/HD Spk Gap 1
24 009280 Cap: .002µF 15 kv C5A,C5B 2
25 029902 High Voltage Transformer SA T1 1
014021 Transformer, 5000VAC 20ma 1
029658 Manf SA HT4000 RHF Csl Flsw 1
26 005140 Flsw:1.20 GPM SPST 1/4 NPT FS1 1
27 005139 Flsw: 0.25 GPM SPST 1/4 NPT FS2 1
28 015014 Adapter 90, 1/4 NPT x #4 1
29 015015 Adapter 90, 1/4 NPT X #6 1
30 015510 Nipple 1/4 X Cl, Hex 2
029882 Harn: HT4001 RHF Csl 1
31 008193 Rcpt Shell: CPC 17-16 Std Sex 2X1 1
32 008205 Pin: 18-16 AWG Type III 12
33 006031 Sol Valve:350# 1/4 FPT 120V NC SV6 1
34 015047 Adapt, 1/4 MNPT X ACC "A" /LH 1
B
