MDE-4602 Gasboy CFN Series Card Encoding Manual · November 2006
Page 7
Card Type Field - Mag Cards only
Card Field Descriptions
3 – Card Field Descriptions
The following are the types of card formats that can be used with CFN Systems:
• Standard format - single or dual card
• Manual entry format - Site Controller I only
• Fuel delivery format
• Supervisor format
• Dipstick format - Site Controller II/III only
• Totalizer format - Site Controller II/III only
• Fueler ID format - Site Controller II/III only
• Code card format
• Fuel Point card - Site Controller II/III only
• Access card - Site Controller II/III only
These formats are described in detail in
. Refer to the card format
that your site uses to determine the field names/sizes that are used.
Note: The field names and sizes in this section may differ from those on your customized card
layout. Customers must contact Customer Service, Technical Assistance Center (TAC)
or their Authorized Service Contractor (ASC) for Card Layouts.
The fields that the card format contains are determined at the time of your order or when you
choose your configuration options. Ensure that you follow your customized layout when
encoding your cards.
Card Type Field - Mag Cards only
The Card Type field applies to Mag Cards only. It is not a data field on the card, but an
indicator of whether the card is a single card or part of a dual card set. If the card is a single
card, the card type indicator is a field separator (-). If it is part of a dual card set, both cards in
the set begin with two field separators (--). For manual entry and fuel delivery cards, the card
type indicator follows the system ID field (See
“Field Separator - Mag Cards only” on page 8
System ID Field - All Cards
The System ID indicated on your card layout, is a unique two to six-digit field assigned by
Gasboy. Its purpose is to protect your system from unauthorized users of other systems. In a
dual card system, the system ID is encoded and verified on both cards. If your system is being
configured to match another Gasboy system, you can use the same system ID.
