Page 5: Change specifics
AGILE DOC ID ER-CMR6000-EB1 THIS DOCUMENT IS NOT SUBJECT TO REVISION/UPDATE! AGILE
C08557
1
Errata B
Comtech EF Data Documentation Update
Subject:
Changes to Appendix F. DVB-S/S2 BER Performance
Date:
June 26, 2009
Original Manual
Part Number:
MNCMR6000.IOM
Rev 1
Errata Number /
Agile Document ID
ER-CMR6000-EB1
Agile CO Number
C08557
Change Specifics:
This information will be incorporated into the next revision. Appendix F, p. F-1:
Test Configuration:
Assumptions:
Symbol Rate: 20 Msps
QEF =
10
‐7
PER
Frame Size = 64,800 (Normal Frames)
Es/No = C/N
Pilots: Off
Roll Off: 35%
Nominal Input Power: -51 dB
L-Band Frequency: 1,170 MHz
Input Range:
-25 to -61 dBm (2 Msps)
-25 to -60 dBm (6 Msps)
-25 to -59 dBm (10 Msps)
-25 to -57 dBm (20 Msps)
-25 to -56 dBm (32 Msps)
Receive signal level Monitor Accuracy ± 10 dB (-25 to -50 dBm)
