• Contact Comtech EF Data Customer Support if the shipment is:
ƒ Incomplete
ƒ Physically damaged
ƒ Inoperable
2.3 Installation
The CMR-6000 is designed for ease of installation and configuration. Once the unit has been
removed from the packing container, please follow these instructions:
Step Procedure
1 Place the unit on a flat surface with free airflow, where the LEDs can be clearly observed and with
unrestricted access to the rear panel of the unit.
2 Until the unit has been fully configured, the coaxial connection to the Low Noise Block (LNB) should
NOT be connected to the unit . If the unit will not be powering the LNB, it is recommended that
'Polarity' (on the 'Tuner' configuration page) be set to 'Off'.
3 Connect the power cable to the power connection on the back of the unit.
4 Connect an RJ-45 Ethernet cable (patch cord) to the port labeled ETHERNET and to an Ethernet
concentrator (hub) or switch.
5 Connect a terminal cable P/N CA-TERMINAL (supplied) to the port labeled TERM and to a PC’s
serial port (DB-9), to initially configure the CMR-6000.
6 Connect AC power (via the power cord) between a standard wall outlet and the CMR-6000.
7 Upon startup, the LEDs on the front panel may illuminate as follows:
Color Label Description
Green / Red STATUS Red indicates error status, green indicates status ok
Green LOCK Solid green indicates the tuner is locked
Green E-LINK
LED illuminates if the Ethernet connection to the Hub/Switch is
operational
Green REDUN
Redundancy indicator. Solid green unit is redundant online and
flashing green is redundant offline (backup)
Amber ASI-TX Solid when ASI is enabled
Amber ASI-RX Solid when ASI input is connected
Amber E-ACT Flashes when there is Ethernet activity
Amber MGT
Solid when management connection (web or Telnet)
