Digicast Media Router S2 Receiver CMR-6000 Revision 1
Introduction MN-CMR6000-IOM
1–4
1.4 Specifications
Parameter Specification
L-Band Tuner
DVB-S ( 2 to 45 Msps) FEC Rates: 1/2, 2/3, 3/4, 5/6 and 7/8
DVB-S2
QPSK ( 2 to 32 Msps) FEC Rates: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9 and 9/10
8PSK ( 2 to 32 Msps) FEC Rates: 3/5, 2/3, 3/4, 5/6, 8/9 and 9/10
Physical
Dimensions 11.375” L x 17” W x 1.75” H (28.8925 L x 43.18 W x 4.445 H cm)
Weight 5.2 lbs. (2.3587 kg)
Power IEC power inlet connector
L-Band Input F-Type (75 Ω)
ASI Input/Output BNC-Type (75 Ω)
Ethernet (10/100BaseT) RJ-45
Terminal RJ-12
Redundancy RJ-12
LEDs
Green/Red STATUS Red indicates error status, green indicates status ok
Green LOCK Solid green indicates the tuner is locked
Green E-LINK
LED illuminates if the Ethernet connection to the
Hub/Switch is operational
Green REDUN
Redundancy indicator. Solid green unit is redundant
online and flashing green is redundant offline (backup)
Amber ASI-TX Solid when ASI is enabled
Amber ASI-RX Solid when ASI input is connected
Amber E-ACT Flashes when there is Ethernet activity
Amber MGT Solid when management connection (web or Telnet)
Electrical
Power Input / Consumption 100 to 240 VAC 47/63 Hz
L-Band Input
DVB-S ETSI EN 300 421
DVB-S2 ETSI EN 302 307
Ethernet (10/100BaseT) IEEE 802.3u
ASI Input/Output EN-50083-9
Console RS-232
Redundancy RS-232
Environmental
Temperature
Operating 32 ° to 122° Fahrenheit (0° to 50° Celsius)
Storage
(Non-operating)
-22 ° to 150° Fahrenheit (-30° to 65° Celsius)
Humidity
Operating 10% to 75% Non-condensing
Storage
(Non-operating)
Relative humidity to 95% with temperature ≤ 95 ° Fahrenheit (35° Celsius)
Altitude
Operating Up to 10,000 feet (3048 m) above sea level
Storage
(Non-operating)
Survival up to 50,000 feet (15240 m) above sea level for up to 15 hours
