Digicast Media Router S2 Receiver CMR-6000 Revision 1
Installation & Initial Configuration MN-CMR6000-IOM
2-3
2.4 Initial Configuration
The initial configuration requires either setting up the IP parameters using the terminal cable or
via the front panel. Once the IP parameters have been configured, the terminal cable can be
removed. Store the terminal cable in a known location, because it may be needed in the future.
To configure the IP parameters:
Step Procedure
1 Using a terminal emulator on a PC such as HyperTerminal™ or TeraTerm™, set up the
communication port as follows:
38,400 BAUD
8 Data Bits
1 Stop Bit
No Parity
No Flow Control
2 Press the key on the PC – the login prompt should be displayed.
3 The default user is comtech and the default password is comtech. After logging in, the CMR-
6000’s menu should be displayed.
4 Press “N” for Network Menu.
5 Press “I” for the IP Address, Enter the IP Address and press .
6 Press “M” for the Subnet Mask. Enter the Subnet Mask and press .
7 Press “G” for the Default Gateway IP Address. Enter the Default Gateway Address and press
.
8 Press “S” to save the parameters.
9 Press “Y” to confirm the saving of parameters.
10 Press “X” to exit to the main menu.
After completing Step 10, the unit has been configured for full IP operation and the terminal
cable may be removed. (For continued operation, the unit may be managed via the Terminal
Interface; however, it is recommended to use the Web Interface for ease of management.)
Additional configuration and management is best performed using the Web interface (refer to
Chapter 4, Device Management Via User Interfaces ). Use of the front panel is described in
Chapter 4 as well.
Once fully configured, the coaxial connection to the Low Noise Block (LNB) may be safely
attached to the L-Band input port.
