MiniMAC Rack Management System
SMS-7000 Protection Switch Screens
Rev. 0
7–5
7.2 Configure
Menus
7.2.1 Lock
Labels
The LOCK LABELS menu functions similar to the SDM-300 menu. The difference is
that the SMS-7000 Switch label is located across the top of the screen, just below the
drop-down menu.
7.2.2
Configure – Alarm Setup
To configure the ALARM SETUP, select CONFIGURE and click on ALARM SETUP.
