MiniMAC Rack Management System Other Devices
Rev. 0 9–15
9.2.1.2 Hexadecimal Digital Masking
Digital masking parameters appear on the MiniMAC screen in hexadecimal format.
However, on the device front panel display, digital masking parameters appear in binary
format.
Eight numbers appear on the top line of the front panel display, and 0s and 1s appear on
the second line.
8 7 6 5 4 3 2 1
1 1 0 1 1 0 1 1
| | | | | | | |
not
masked
not
masked
masked not
masked
not
masked
masked not
masked
not
masked
|______ Binary 1101 = Hex D _______| |______ Binary 1011 = Hex B _______|
The 0s represent masked faults, 1s represent unmasked faults. The 0s and 1s also
represent a set of two binary numbers. In the example above, binary 1101 = hex D, and
binary 1011 = hex B.
Use the following chart to convert binary values that match the desired masked/unmasked
faults settings into hex values.
Binary Hex Binary Hex
0000 0 1000 8
0001 1 1001 9
0010 2 1010 A
0011 3 1011 B
0100 4 1100 C
0101 5 1101 D
0110 6 1110 E
0111 7 1111 F
Then, select the appropriate hex values from the drop-down selection list for each digital
masking parameter on the MiniMAC screen.
