CRS-400 1:8 Redundancy Switch Revision 0
Remote Control MN/CRS400.IOM
46
A.3.4.2 (CONFIG, REM CONTROL) SETTINGS
REMOTE CONTROL: FORMAT
BAUD TYPE ADDRESS (ENT)
Because remote monitoring is available at all times, the remote control settings may be
set without the need to be in REMOTE mode.
Select FORMAT, BAUD, TYPE, or ADDRESS using the LEFT/RIGHT arrow keys,
then press ENTER.
A.3.4.2.1 (CONFIG, REM, SETTINGS) FORMAT
SELECT DATA FORMAT:
8-N-1 7-E-2 7-O-2 (ENT)
Select the data format for the remote control using the RIGHT/LEFT arrow keys, and
press ENTER. Possible format choices are listed below:
8-N-1 = 8 data bits No parity 1 stop bit
7-E-2 = 7 data bits Even parity 2 stop bits
7-O-2 = 7 data bits Odd parity 2 stop bits
A.3.4.2.2 (CONFIG, REM, SETTINGS) BAUD
EDIT SWITCH BAUDRATE:
19200 BAUD (PRESS ENTER)
Edit the baud rate of the remote control bus connected locally to the M&C computer.
Change the value using the UP/DOWN arrow keys, and press ENTER.
Possible Baud Values:
300 1200 2400 4800 9600 19200
A.3.4.2.3 (CONFIG, REM, SETTINGS) TYPE
INTERFACE TYPE: RS232
RS485-2W RS485-4W (ENT)
Select RS232, RS485 (2-wire), or RS485 (4-wire). Use the LEFT/RIGHT arrow keys to
select an interface type, then press ENTER.
Note: RS-485 2-wire is available, but not preferred.
In RS232 mode the bus address is fixed at 0, and the following screen is displayed:
