CRS-400 1:8 Redundancy Switch
Revision 0
Remote Control
MN/CRS400.IOM
45
A.3.2
(CONFIG) AUTO[OFF
OR
ON]
OPERATING MODE:
AUTO-OFF AUTO-ON (ENTER)
Use this option to turn Auto mode OFF or ON. When Auto Mode is OFF, the switch is
said to be in Manual mode, and the following conditions apply:
The switch does not respond automatically to any mod/demod faults. It simply
performs whatever manual setting was selected on the previous menu.
The STORED EVENT indicator blinks to alert the user that automatic switching will
not occur.
If Dependent, the mods/demods are activated as a pair.
If Independent, the mods and demods are each activated separately, as required.
A.3.3 (CONFIG) ACTIVE
ACTIVE MODEMS: (ENTER)
1 2 3 - 5 6 - 8
A TMI must be present in order for a mod/demod to be activated. A “-“ (hyphen)
indicates an inactive unit. Move the cursor left/right to the desired unit and press the UP
key. The unit number will show in that position. Press ENTER. Similarly, press DOWN
to deactivate a unit.
A.3.4 (CONFIG) REMOTE CONTROL
SELECT REMOTE CONTROL:
LOC/REM SETTINGS (ENT)
Select LOC/REM or SETTINGS using the LEFT/RIGHT arrow keys, then press ENTER.
A.3.4.1 (CONFIG, REM CONTROL) LOC/REM
SELECT REMOTE CONTROL:
LOCAL REMOTE (PRESS ENT)
If LOCAL is selected, remote control is disabled, but remote monitoring is still possible,
so the remote control settings are displayed.
If REMOTE is selected, then remote control is enabled, and the remote control settings
are available.
