Comtech EF Data RCS11 User Manual
Page 93
RCS11 1:1 Redundancy Switch
RCS11 DIP Switch Configurations
MN-RCS11 – Revision 9
A–5
Figure A-5 Illustrates standard jumper blocks for fault execution on all Radyne products. J4 and
JP1 Shunt Blocks should be installed as a factory default configuration.
J4 and JP1 Shunt Blocks
Figure A-5. J4 and JP1 Shunt Blocks
