RCS11 1:1 Redundancy Switch RCS11 Remote Communications
MN-RCS11 – Revision 9 B–7
IMPORTANT
When transmitting a packet at 9600 baud, the Remote M&C should ensure
that the timeout value between characters does not exceed the time it takes to
transmit 200 characters (

200 msec). If this timeout value is exceeded, the
equipment will timeout.
Regular Commands
Opcode <2000h>
Query RCS11 Device Identification
Query Response Data Field (1 byte):
<1>
Device Identification 26 decimal for RCS11
Opcode <2080h>
Query RCS11 Device Firmware Version
Query Response Data Field (19 bytes):
<1>
Device Firmware Version MSB binary number, implied decimal point
<1> Device Firmware Version LSB binary number, implied decimal point
<10> Device Firmware Name null terminated string
<7> Device Firmware Release Date null terminated string
Opcode <2280h>
Command RCS11 Load Factory Defaults
Command Data Field (2 bytes):
<1>
Unlock Code 1 0x55
<1> Unlock Code 2 0xAA
Opcode <2083h>
Query RCS11 Backup Configuration
Query Response Data Field (1 byte):
<1>
Backup Configuration 0 = Modem (Coupled)
1 = Mod Only
2 = Demod Only
3 = Mod/Demod (Uncoupled)
Opcode <2084h>
Query RCS11 Backup Mode
Query Response Data Field (1 byte):
<1>
Backup Mode 0 = Manual
1 = Automatic
2 =
Opcode <2284h>
Command RCS11 Backup Mode
Command Data Field (1 byte):
<1>
Backup Mode 0 = Manual
1 = Automatic
Opcode <2085h>
Query RCS11 Backup State
Query Response Data Field (2 bytes):
<1>
Mod Backup state 0 = A online
1 = B online
2 =
<1>
Demod Backup State 0 = A online
