DMD20/DMD20LBST Universal Satellite Modem Technical Specifications
MN-DMD20-20LBST – Rev. 11 7–2
DMD20: Synch : RS530/ V.35/RS232
Universal : RS530/V.35/RS232/G.703/IDR & IBS
Alarms/Drop & Insert, ASI/Parallel, HSSI,
Ethernet
: 10/100 Base-T/RS530
DMD50: Synch : RS530/ V.35/RS232
Universal : RS530/V.35/RS232/G.703/
IDR & IBS Alarms/Drop & Insert,
Universal
: G703 (T3, E3, STS1) / HSSI
Universal : ASI
Ethernet 10/100 Base-T/RS530
DMD2050: Synch : RS530/ V.35/RS232 (MIL-188-144)
Universal : RS530/V.35/RS232/G.703/
IDR & IBS Alarms/Drop & Insert,
Universal
: G703 (T3, E3, STS1) / HSSI
Universal : ASI
Ethernet 10/100 Base-T/RS530
7.5 Front Panel LED Indicators
Unit: Power Supply 1
Power Supply 2
Switch Fault
Auto
Manual
Demodulator: Online A/B
Fault A/B
Modulator: Online
A/B
Fault A/B
Front Panel Controls
Enable
Select Auto
Mod Select A
Mod Select B
Demod Select A
Demod Select B
7.6 Power and Environmental
Prime Power: 100 to 240 VAC, 50 to 60 Hz, 40 Watts
Operating Temperature: 0 to 50°C, 95% Humidity, Noncondensing
7.7 Storage Temperature: -20 to 70°C, 99% Humidity, Noncondensing
Physical
Chassis Size Long: 21.75” L x 19” W x 1.75” H
(55.24 cm x 48.26 cm x 4.45 cm)
9 Pounds (4.08 Kg)
Chassis Size Short:
16.5” L x 19” W x 1.75” H
(41.91 cm x 48.26 cm x 4.45 cm)
8 Pounds (3.62 Kg)
