RCS11 1:1 Redundancy Switch Connector Pinouts
MN-RCS11 – Revision 9 5–12
5.7.2 Terrestrial Data (J10) DVB Parallel Interface
The Terrestrial Data (J10) DVB Parallel Interface is a 25-Pin Female ‘D’ port. Refer to Table 5-14
for pinouts.
Table 5-14. J10 Terrestrial Data (DVB Parallel) (25-Pin Female 'D')
Pin # Description Signal
1 Clock + Input
2, 15 System Ground GND
3 D7 + Input
4 D6 + Input
5 D5 + Input
6 D4 + Input
7 D3 + Input
8 D2 + Input
9 D1 + Input
10 D0 + Input
11 DVALID + Input
12 PSYNC + Input
13 Cable Shield Input
14 Clock - Input
16 D7 - Input
17 D6 - Input
18 D5 - Input
19 D4 - Input
20 D3 - Input
21 D2 - Input
22 D1 - Input
23 D0 - Input
24 DVALID - Input
25 PSYNC - NA
