RCS11 1:1 Redundancy Switch

RCS11 Remote Communications

MN-RCS11 – Revision 9

B–9


Opcode: <2089h>

Query RCS11 Switch Alarms Mask

Query Response Data Field (4 Bytes):
<1>

External Alarm Masks

1 = Enabled, 0 = Masked Off

Bit 0: 1 = Mod A Alarm Enabled
Bit 1: 1 = Force Mod A Alarm Enabled
Bit 2: 1 = Demod A Alarm Enabled
Bit 3: 1 = Force Demod A Alarm Enabled
Bit 4: 1 = Mod B Alarm Enabled
Bit 5: 1 = Force Mod B Alarm Enabled
Bit 6: 1 = Demod B Alarm Enabled
Bit 7: 1 = Force Demod B Alarm Enabled


<1>

Switch Alarm Masks

1 = Enabled, 0 = Masked Off

Bit 0: 1 = Switch Power 1 Alarm Enabled
Bit 1: 1 = Switch Power 2 Alarm Enabled
Bit 2: 1 = Switch Firmware Error Enabled
Bit 3: 1 = Switch NV Alarm
Bit 4: 1 = Switch Internal Alarm Enabled
Bit 5..7: unused, return 0


<2>

Spare Current Alarms

Always 0

Opcode: <2289h>

Command RCS11 Switch Alarms Masks

Command Data Field (4 Bytes):
<1>

External Alarm Masks

1 = Enabled, 0 = Masked Off

Bit 0: 1 = Mod A Alarm Enabled
Bit 1: 1 = Force Mod A Alarm Enabled
Bit 2: 1 = Demod A Alarm Enabled
Bit 3: 1 = Force Demod A Alarm Enabled
Bit 4: 1 = Mod B Alarm Enabled
Bit 5: 1 = Force Mod B Alarm Enabled
Bit 6: 1 = Demod B Alarm Enabled
Bit 7: 1 = Force Demod B Alarm Enabled


<1>

Switch Alarm Masks

1 = Enabled, 0 = Masked Off

Bit 0: 1 = Switch Power 1 Alarm Enabled
Bit 1: 1 = Switch Power 2 Alarm Enabled
Bit 2: 1 = Switch Firmware Error Enabled
Bit 3: 1 = Switch NV Alarm Enabled
Bit 4: 1 = Switch Internal Alarm Enabled
Bit 5..7: unused, 0 filled


<2>

Spare Current Alarms

0 filled
