RCS11 1:1 Redundancy Switch

Connector Pinouts

MN-RCS11 – Revision 9

5–18

3 Ground

GND

4

Tx Audio 2B

Input

5

Rx Audio 2A

Output

6

Tx Audio 1B

Input

7

Rx Audio 1B

Output

8

Tx Audio 2A

Input

9

Rx Audio 2A

Output

5.8.5 ESC Alarms (J17)

The ESC Alarm Port is a 25-Pin Female ‘D’ Connector. Refer to Table 5-22 for pinouts.

Table 5-22. J17 ESC ALARMS (25-Pin Female 'D')

Pin #

Description

Signal

1, 7

Ground

GND

2

Backward Alarm Out 1

Normally Open

3, 5, 9, 12, 13, 24, 25

Not Used

NA

4

Backward Alarm Out 2

Normally Open

6

Backward Alarm Out 3

Normally Open

8

Backward Alarm Out 4

Normally Open

10

Backward Alarm In 2

Input

11

Backward Alarm In 4

Input

14

Backward Alarm Out 1

Common

15

Backward Alarm Out 1

Normally Closed

16

Backward Alarm Out 2

Common

17

Backward Alarm Out 2

Normally Closed

18

Backward Alarm Out 3

Common

19

Backward Alarm Out 3

Normally Closed

20

Backward Alarm Out 4

Common

21

Backward Alarm Out 4

Normally Closed

22

Backward Alarm In 1

Input

23

Backward Alarm In 3

Input
