RCS11 1:1 Redundancy Switch Connector Pinouts
MN-RCS11 – Revision 9 5–4
6 Receive Data (A) - Output
7 Request To Send (A) - Input
8 Receive Timing (A) - Output
9 Cllear To Send (A) - Output
11 Data Mode (A) - Output
13 Receive Ready (A) - Output
15 External Clock (A) - Input
16 Receive Octet (A) - Output
17 Terminal Timing (A) - Input
21 Transmit Octet (B) + Input
22 Send Data (B) + Input
23 Send Timing (B) + Output
24 Receive Data (B) + Output
25 Request To Send (B) + Input
26 Receive Timing (B) + Output
27 Clear To Send (B) + Output
29 Data Mode (B) + Output
31 Receive Ready (B) + Output
33 External Clock (B) + Input
34 Receive Octet (B) + Output
35 Terminal Timing (B) + Input
5.5.2 MODEM A & B (J7 & J11) G703/RS422 Serial Universal Interface
w/SCSI
connectors
The Modem Channel a Port is a 68-Pin High-Density Female SCSI Connector. This port is the
data interface used to connect to the primary and backup modems. This interface supplies the
RS422 Synchrounous, G703, IDR and IBS data information from the modems. Refer to Table 5-
5 for pinouts.
Table 5-5 J7 & J11 MODEM A (68-Pin Female High Density Connector)
Pin No. Description Signal
1 G.703 Send Data (A) - Output
2 Synch Data Send Data (A) - Output
3 IDR ESC Backward Alarm 1 Common
4 G.703 Insert Data Input (A) - Output
5 Synch Data Send Timing (A) - Input
6 IDR ESC Backward Alarm 1 Normally Open
7 Synch Data Terminal Timing (A) - Output
8 IDR ESC Backward Alarm 2 Normally Closed
9 G.703 Drop Data Out (A) - / Synch Data Receive Timing (A)- Input
