• Optional end-to-end cyclic redundancy code (ECRC) generation and checking and advanced error
reporting (AER) for high reliability applications.
• Support for Arria 10 Avalon-MM DMA for PCI Express with either a 128- or 256-bit interface to the
Application Layer. This variant includes an embedded DMA controller for data transfers. The
following table shows the available configurations.
• Easy to use:
• Flexible configuration.
• No license requirement.
• Example designs to get started.
Table 1-2: Feature Comparison for all Hard IP for PCI Express IP Cores
The table compares the features of the four Hard IP for PCI Express IP Cores.
Feature Avalon-ST Interface Avalon-MM
Interface
Avalon-MM DMA Avalon-ST Interface with SR-
IOV
IP Core License Free Free Free Free
Native
Endpoint
Supported Supported Supported Supported
Legacy
Endpoint (1)
Supported Not Supported Not Supported Not Supported
Root port Supported Supported Not Supported Not Supported
Gen1 ×1, ×2, ×4, ×8 ×1, ×2, ×4, ×8 Not Supported
×8
Gen2 ×1, ×2, ×4, ×8 ×1, ×2, ×4, ×8 ×4, ×8
×4, ×8
Gen3 ×1, ×2, ×4, ×8 ×1, ×2, ×4 ×2, ×4, ×8
×2, ×4, ×8
64-bit Applica‐
tion Layer
interface
Supported Supported Not supported Not supported
128-bit
Application
Layer interface
Supported Supported Supported Supported
256-bit
Application
Layer interface
Supported Not Supported Supported Supported
(1) Not recommended for new designs.
