74

ControlLogix

Analog HART Modules

Table 7.2(Packet 1)

Tag Name

Data Type

Style

Description

(If8h0 or Of8h0)Packet1

1

Packet1[8,1] NA

Two dimensional array containing
packet 1 data for all 8 channels.

(If8h0 or Of8h0)Packet1[X,0]

1,2

Packet1

NA

Packet 1 data for channel X

(If8h0 or Of8h0)Packet1[X,0].HartChannelID

INT

BIN

Bits 0 to 3: Channel number (0 – 7).
Bit 4: Searching/Initializing HART device
Bit 5: HART communication failure or
device not found
Bit 6: Pass-through message pending
(ready)
Bit 7: Unused (0)
Bits 8 to 10: Packet ID
Bit 11 through 15: Unused

(If8h0 or Of8h0)Packet1[X,0].HartCommStatus

SINT

BIN

HART communication status byte. Refer to
appendix D for more details.

(If8h0 or Of8h0)Packet1[X,0].HartDevStatus

SINT

BIN

HART device status byte. Refer to appendix D
for more details.

(If8h0 or Of8h0)Packet1[X,0].HartPV

REAL

FLOAT

HART Primary Variable

(If8h0 or Of8h0)Packet1[X,0].HartSV

REAL

FLOAT

HART Secondary Variable

(If8h0 or Of8h0)Packet1[X,0].HartTV

REAL

FLOAT

HART T ertiary Variable

(If8h0 or Of8h0)Packet1[X,0].HartFV

REAL

FLOAT

HART Fourth Variable

(If8h0 or Of8h0)Packet1[X,0].HartPVUnits

SINT

DEC

HART Primary Variable units code

(If8h0 or Of8h0)Packet1[X,0].HartSVUnits

SINT

DEC

HART Secondary Variable units code

(If8h0 or Of8h0)Packet1[X,0].HartTVUnits

SINT

DEC

HART T ertiary Variable units code

(If8h0 or Of8h0)Packet1[X,0].HartFVUnits

SINT

DEC

HART Fourth Variable units code

(If8h0 or Of8h0)Packet1[X,0].PV_Assignment

SINT

DEC

HART Primary Variable code

(If8h0 or Of8h0)Packet1[X,0].SV_Assignment

SINT

DEC

HART Secondary Variable code

(If8h0 or Of8h0)Packet1[X,0].TV_Assignment

SINT

DEC

HART T ertiary Variable code

(If8h0 or Of8h0)Packet1[X,0].FV_Assignment

SINT

DEC

HART Fourth Variable code

(If8h0 or Of8h0)Packet1[X,0].RangeLow

REAL

FLOAT Low transmitter range for analog signal in

engineering units

(If8h0 or Of8h0)Packet1[X,0].RangeHi

REAL

FLOAT High transmitter range for analog signal in

engineering units

(If8h0 or Of8h0)Packet1[X,0].Pad

SINT[4]

DEC

Packet pad (32 bit alignment)

1

The name in parentheses represents the module tag name (i.e. If8h0 or Of8h0) depending on w hich module is being used.

2

X represents the module channel number (0 to 7)
