2

ControlLogix

Analog HART Modules

Input Ranges

The following tables provide compatibility information on the supported
millivolt and voltage input and output types supported by the modules.

Table 1.1 1756sc-IF8H Input Ranges

0 to 5 V

(0 to +5.125 V)

0 to 10 V

(0 to +10.25 V)

-10 to +10 V

(-10.25 to +10.25 V)

4 to 20 mA

(3.42 to +20.58 mA)

0 to 20 mA

(0 to +20.58 mA)

Table 1.2 1756sc-OF8H Output Ranges

-10 to +10 V

(-10.4 to +10.4 V)

0 to 20 mA

(0 to +21.5 mA)

Eight channels are individually configurable for voltage or current input/
output types. Each channel provides wire-off input, over-range, and
under-range detection and indication, when enabled.

Hardware Features

The modules fit into any single slot within a ControlLogix modular system.
The modules use a unique generic profile which may be configured using
your RSLogix 5000 programming software.

The modules utilize a removable terminal block, that provides connections
for the eight channels. The module is configured through RSLogix 5000
software, defining current or voltage inputs/outputs.

Table 1.3 Hardware Features

Hardware

Function

OK LED

Displays communication and fault status

Cal LED

Displays a calibration related condition

Side Label (Nameplate)

Provides module information

Removable Terminal Block

Electrical connection to devices

Door Label

Permits easy terminal identification

Self Locking Tabs

Secure module in chassis slot

Terminal Block Switch

Locks the RTB to the module.
