Chapter 5: 1756sc-IF8H Channel Configuration, Data, and Status

37

Configuration, Data,

Configuration, Data,

Configuration, Data,

Configuration, Data,

Configuration, Data,

and Sta

and Sta

and Sta

and Sta

and Status

tus

tus

tus

tus TTTTTaaaaags

gs

gs

gs

gs

for the 1756sc-IF8H

for the 1756sc-IF8H

for the 1756sc-IF8H

for the 1756sc-IF8H

for the 1756sc-IF8H

Read this chapter to:

Send configuration data to the module

• Configuration tags

Module filter selection

• Module input tags

• Accessing the module tags

Changing configuration information at the tags

This chapter outlines the detailed settings for the 1756sc-IF8H. These
settings determine the modules input types, filter frequencies, scan rates,
and various attributes. Detailed descriptions of these settings are available
in the Tag Definition section of this chapter.

Note: The following format is used to describe tags

Tag Name Data Type Style Description

S e n d

S e n d

S e n d

S e n d

S e n d

C o n f i g u r a t i o n

C o n f i g u r a t i o n

C o n f i g u r a t i o n

C o n f i g u r a t i o n

C o n f i g u r a t i o n

Data to the

Data to the

Data to the

Data to the

Data to the

M o d u l e

M o d u l e

M o d u l e

M o d u l e

M o d u l e

After changing the configuration tags in this chapter you must then send
them to the module. To do this you may perform any of these operations:

1. Inhibit then un-inhibit the module via the module properties dialog,
Connection Tab

2. Reset the module via the modules properties dialog. Module Info tab.

3. Reset the module via ladder logic. See the “DoReset” rung in the
sample ladder located in Chapter 8.

4. Perform a “Set Attribute All” or Module Reconfigure message
instruction via ladder logic. Refer to Chapter 8 for information about the
“DoSetAttrAll” command.

Note: If an invalid configuration is sent to the module a connection error
will occur. See chapter 9 for a list of error codes.
