Chapter 6: 1756sc-OF8H Channel Configuration, Data, and Status

57

Table 6.1f

Tag Name

Data Type Style Description

Of8h0Configuration.ModuleConfigBits.14

2

BOOL

DEC Bits 14 and 15 determine how often

the pass-through command is
serviced by the module.
15,14 = 00 = pass-through serviced
once per two channels scanned
15,14 = 01 = pass-through serviced
once per module scan
15,14 = 1X = pass-through serviced
once per channel scan

Of8h0Configuration.ModuleConfigBits.15

2

BOOL

DEC Bits 14 and 15 determine how often

the pass-through command is
serviced by the module.
15,14 = 00 = pass-through serviced
once per two channels scanned
15,14 = 01 = pass-through serviced
once per module scan
15,14 = 1X = pass-through serviced
once per channel scan

2

The configuration of bits 14 and 15 directly effect the update time of the HART data acquisition for the module, for

example if bit 15 is set, the HART update time for each channel w ill be doubled.

Input

Input

Input

Input

Input T

TT

T

Taaaaags

gs

gs

gs

gs

The following fault and status reporting and module data sections allow
monitoring of faults, status, and input data from the module. These tags
can be found within the Of8h0Input controller tag.
