Chapter 5: 1756sc-IF8H Channel Configuration, Data, and Status

45

Table 5.3b

Tag Name

Data Type

Style Description

If8h0Input.ModuleStatus.13

BOOL

DEC

Channel 5 broken wire
0 = Connection
1 = Open circuit

If8h0Input.ModuleStatus.14

BOOL

DEC

Channel 6 broken wire
0 = Connection
1 = Open circuit

If8h0Input.ModuleStatus.15

BOOL

DEC

Channel 7 broken wire
0 = Connection
1 = Open circuit

If8h0Input.ModuleStatus.16

BOOL

DEC

Channel 0 HART out-of-service
0 = In service
1 = Out-of-service

If8h0Input.ModuleStatus.17

BOOL

DEC

Channel 1 HART out-of-service
0 = In service
1 = Out-of-service

If8h0Input.ModuleStatus.18

BOOL

DEC

Channel 2 HART out-of-service
0 = In service
1 = Out-of-service

If8h0Input.ModuleStatus.19

BOOL

DEC

Channel 3 HART out-of-service
0 = In service
1 = Out-of-service

If8h0Input.ModuleStatus.20

BOOL

DEC

Channel 4 HART out-of-service
0 = In service
1 = Out-of-service

If8h0Input.ModuleStatus.21

BOOL

DEC

Channel 5 HART out-of-service
0 = In service
1 = Out-of-service

If8h0Input.ModuleStatus.22

BOOL

DEC

Channel 6 HART out-of-service
0 = In service
1 = Out-of-service

If8h0Input.ModuleStatus.23

BOOL

DEC

Channel 7 HART out-of-service
0 = In service
1 = Out-of-service

If8h0Input.ModuleStatus.24

BOOL

DEC

Unused

If8h0Input.ModuleStatus.25

BOOL

DEC

Calibration fault
0 = No fault
1 = Fault

If8h0Input.ModuleStatus.26

BOOL

DEC

Calibration in progress
0 = Calibration NOT active
1 = Calibrating

If8h0Input.ModuleStatus.27

BOOL

DEC

Unused

If8h0Input.ModuleStatus.28

BOOL

DEC

Unused

If8h0Input.ModuleStatus.29

BOOL

DEC

Unused

If8h0Input.ModuleStatus.30

BOOL

DEC

Unused

If8h0Input.ModuleStatus.31

BOOL

DEC

Analog group fault
0 = No fault
1 = Fault
