1756sc-IF8H Module Specifications

1756sc-IF8H Module Specifications

1756sc-IF8H Module Specifications

1756sc-IF8H Module Specifications

1756sc-IF8H Module Specifications

This appendix lists the specifications for the 1756sc-IF8H Analog Input
module.

Electrical Specifications
1756sc-IF8H

Parameter

Specification

Number of Inputs8 differential voltage or current inputs

Module Location

ControlLogix or ProcessLogix Chassis

Power Consumption

300mA @ 5.1V

70mA @ 24V

Power Dissipation within Module

3.21W – voltage / 4.01W – current

Thermal Dissipation

11.0 BTU/hr – voltage / 13.7 BTU/hr – current

Input Ranges

+/-10.25 V

0 – 10.25 V

0 – 5.125 V

0 – 20.58 mA

3.42 – 20.58 mA

Data Format

IEEE 754 32 bit Floating point

Input Impedance

> 1 M

∧ – voltage

249 ohms – current

Open Circuit Detection Time

5 seconds

Input Overvoltage Protection

30V DC – voltage

8V DC – current

Normal Mode Noise Rejection

Filter Frequency -3dB Frequency

50 Hz Rejection (dB) 60 Hz Rejection (dB) Effective

Resolution

10 Hz

7.80 Hz

95

97

16

15 Hz

11.70 Hz

85

88

16

20 Hz

15.60 Hz

38

65

16

50 Hz

39.30 Hz

4

7

16

60 Hz

39.30 Hz

4

7

16

100 Hz

65.54 Hz

2

2.5

16

250 Hz

163.9 Hz

0.5

0.6

14

1000 Hz

659.7 Hz

0.1

0.1

12

Common Mode Noise Rejection

> 100 dB at 50/60Hz (10 Hz filter)

Calibrated Accuracy at 25°C

Better than 0.05% of range – voltage

Better than 0.15% of range – current

Input Offset Drift with Temperature

<= 90 uV/°C
