12
Face Down Offset Stapler
If the optional face down offset stapler is connected, you can staple printed sheets, or perform the offset output by print unit.
a Stacking Tray
Printouts are output face down.
The output tray slides. For normal output, align  and 
indicated by b to use the tray.
Tray setting position Paper type and output
conditions

Align  and  .
Normal (other than the
following)


Slide the tray and place 
to b
For thin paper smaller than
B5 without staple
c Jam Release Cover
If paper jamming occurs during paper transfer from the
printer to the face down offset stapler, open this cover and
remove the jammed sheet.
d Staple Cartridge
Pull out the staple cartridge to replace a staple or if a staple
is jammed.
e Staple Cover
Open this cover if a staple is jammed, or to replace the staple
cartridge.
f Face Down Offset Stapler Socket
Connect the face down offset stapler power cord.
ComColor Series Basic Guide 02
