11
Preparations for Use >> Read This First
1
e Paper Feed Pressure Adjustment Lever
Use to adjust the paper feed pressure to suit the paper type
in the standard tray.
f Standard Tray Paper Guide
Use to prevent paper in the standard tray from becoming
misaligned.
g Paper Feed Guide Lever
Use to slide or fix the standard tray paper guide. Levers are located
on both sides of the standard tray paper guide, in two positions.
h Main Power Switch
Use to turn the main power ON and OFF. Usually the power is
left ON.
When the high capacity feeder is connected, use its main
power switch. See "High Capacity Feeder" (p. 13) for details.
i Scanner Socket
Use to connect the scanner power cord.
j Machine Socket
Use to connect the machine power cord.
k Standard Tray Descent Button
Use to move the standard tray up or down when replacing or
adding paper to it.
l Feed Tray
Set the paper to be used for printing here. Special paper
such as thick paper cannot be set. For details, see "Paper and
Originals" (p. 27).
m USB Port
Use to connect a USB flash drive to store scanner data or to
output print jobs saved in a USB flash drive.
Use USB flash drive compatible with Mass Storage Class
and USB 1.1 or 2.0 specifications.
n Scanner
Use to copy or scan documents that are read from the platen
glass or the ADF.
o Scanner Lamp (green/red)
Lights up in green when the scanner is ready to be used.
Flashes in green when starting up or while reading, and
flashes in red when an error occurs.
p Platen Glass
Set the original face down and aligned with the position of
the arrow in the top left.
q Original Cover
Pull down to cover the original when reading it on the platen
glass.
r Automatic Document Feeder (ADF)
Up to about 100 originals can be automatically fed.
s ADF Original Unit Lever
Pull this lever up to open the original unit cover when
originals are jammed.
t ADF Original Guide
Slide to fit the width of the original.
u ADF Original Output Tray
Documents that are read from the ADF are output here.
v Scanner Power Switch
Use to turn scanner power ON and OFF. Usually the power is
left ON.
ComColor Series Basic Guide 02
