Chapter 4 BIOS Setup
LittleBoard 735 Reference Manual 59
• SouthBridge Configuration
• USB Functions – [Disabled; 2 USB Ports; 4 USB Ports; 6 USB Ports]
• USB 2.0 Controller – [Enabled; Disabled]
• AC’97 Audio Controller – [Enabled; Disabled]
• SMBus Controller – [Enabled; Disabled]
• High Precision Event Timer – [Enabled; Disabled]
• SLP_S4# Min. Assertion Width – [4 to 5 seconds; 3 to 4 seconds; 2 to 3 seconds;
1 to 2 seconds]
• Restore on AC Power Loss – [Power Off; Power On; Last State]
BIOS Exit Setup Screen
Figure 4-7. BIOS Exit Setup Screen
Save Changes and Exit
The < F10 > key can be used for this operation.
Discard Changes and Exit
The < ESC > key can be used for this operation.
Discard Changes
The < F7 > key can be used for this operation.
Load Optimal Defaults
The < F9 > key can be used for this operation.
Load Failsafe Defaults
The < F8 > key can be used for this operation.
BIOS Setup Utility
Exit Options
Select Screen
Exit system setup
after saving the
changes.
F10 key can be used
for this operation.
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
x02.xx (C) Copyright 1985-20xx, American Megatrends, Inc.
Save Changes and Exit
Discard Changes and Exit
Discard Changes
Load Optimal Defaults
Load Failsafe Defaults
Main Advanced PCIPnP Boot Security Chipset Exit
LB735_BIOS_ExitScreen_a
