Chapter 4 BIOS Setup
LittleBoard 735 Reference Manual 49
• IDE Configuration
♦ ATA/IDE Configuration [Disabled; Compatible; Enhanced]
• Legacy IDE Channels [SATA Only; Reserved; SATA Pri, PATA Sec; PATA Only]
♦ Primary IDE Master : [Not Detected]
• Type – [Not Installed; Auto; CD/DVD; ARMD]
• LBA/Large Mode – [Disabled; Auto]
• Block (Multi-Sector Transfer) – [Disabled; Auto]
• PIO Mode – [Auto; 0; 1; 2; 3; 4]
• DMA Mode – [Auto]
• S.M.A.R.T. – [Auto; Disabled; Enabled]
• 32Bit Data Transfer – [Disabled; Enabled]
♦ Primary IDE Slave : [Not Detected]
• Type – [Not Installed; Auto; CD/DVD; ARMD]
• LBA/Large Mode – [Disabled; Auto]
• Block (Multi-Sector Transfer) – [Disabled; Auto]
• PIO Mode – [Auto; 0; 1; 2; 3; 4]
• DMA Mode – [Auto]
• S.M.A.R.T. – [Auto; Disabled; Enabled]
• 32Bit Data Transfer – [Disabled; Enabled]
♦ Secondary IDE Master : [Not Detected]
• Type – [Not Installed; Auto; CD/DVD; ARMD]
• LBA/Large Mode – [Disabled; Auto]
• Block (Multi-Sector Transfer) – [Disabled; Auto]
• PIO Mode – [Auto; 0; 1; 2; 3; 4]
• DMA Mode – [Auto]
• S.M.A.R.T. – [Auto; Disabled; Enabled]
• 32Bit Data Transfer – [Disabled; Enabled]
♦ Secondary IDE Slave : [Not Detected]
• Type – [Not Installed; Auto; CD/DVD; ARMD]
• LBA/Large Mode – [Disabled; Auto]
• Block (Multi-Sector Transfer) – [Disabled; Auto]
• PIO Mode – [Auto; 0; 1; 2; 3; 4]
• DMA Mode – [Auto]
• S.M.A.R.T. – [Auto; Disabled; Enabled]
• 32Bit Data Transfer – [Disabled; Enabled]
♦ Hard Disk drive Write Protect – [Disabled; Enabled]
♦ IDE Detect Time Out (Sec) – [0; 5; 10; 15; 20; 25; 30; 35]
♦ ATA (PI) 80Pin Cable Detection – [Host & Device; Host; Device]
