Chapter 4 BIOS Setup
46 Reference Manual LittleBoard 735
If Quick Boot is set to [Enabled], you may never see the screen prompt.
10. Use the key to select the screen menus listed in the Opening BIOS screen.
PCI-to-ISA Bridge Mapping
The LittleBoard 735 supports ISA bus based modules with an on-board PCI-to-ISA bridge. The PCI-to-ISA
bridge optionally maps the following resources to ISA based modules:
• IRQs
• DMA Channels
The LittleBoard 735 system BIOS, maps the above resources based on information provided in the BIOS
Setup screens. By default, IRQs or DMA channels to be mapped to ISA modules must be explicitly specified
by the user in the BIOS Setup screens.
The IRQs and DMA channels are mapped with the “PCIPnP/IRQx” fields in BIOS setup (where x specifies
the IRQ number.) The IRQs 3, 4, 5, 7, 9, 10, 11, 14, and 15 can be mapped to ISA based modules by
changing the default setting for these IRQs from “Available” to “Reserved”.
Any of the DMA channels 0, 1, 3, 5, 6, 7 can be mapped to ISA modules by changing the default setting of
“Available” to “Reserved”.
Logo Screen Utility (Splash Screen)
The LittleBoard 735 BIOS supports a graphical logo utility, which can be customized by the user and
displayed when enabled through the BIOS Setup Utility. The graphical image can be a company logo or any
custom image the user wants to display during the boot process. The custom image can be displayed as the
first image displayed on screen during the boot process and remain there, depending on the options selected
in BIOS Setup, while the OS boots.
Logo Screen Image Requirements
The user’s image may be customized with any standard image editing tool.
The LittleBoard 735 logo screen utility supports the following image formats:
• Bitmap image
• Exactly 640 x 480 pixels
• Exactly 16 colors
• Bitmap image
♦ 16-Color, 640x480 pixels
♦ 256-Color, 640x480 pixels
• JPG image
♦ 16-Color, 640x480 pixels
• PCX image
♦ 256-Color, 640x480 pixels
• A file size no larger than the sample image
NOTE The serial console port is not hardware protected. Diagnostic software that
probes hardware addresses may cause a loss or failure of the serial console
functions.
