Chapter 4 BIOS Setup
54 Reference Manual LittleBoard 735
BIOS PCIPnP Setup Screen
Figure 4-3. BIOS PCIPnP Setup Screen
• Clear NVRAM – [No; Yes]
• Plug & Play O/S – [No; Yes]
• PCI Latency timer – [32; 64; 96; 128; 160; 192; 224; 248]
• Allocate IRQ to PCI VGA – [Yes; No]
• Palette Snooping – [Disabled; Enabled]
• PCI IDE BusMaster – [Disabled; Enabled]
• OffBoard PCI/ISA IDE Card – [Auto; PCI Slot1; PCI Slot2; PCI Slot3; PCI Slot4]
• IRQ3 – [Available; Reserved]
• IRQ4 – [Available; Reserved]
• IRQ5 – [Available; Reserved]
• IRQ6 – [Available; Reserved]
• IRQ7 – [Available; Reserved]
BIOS Setup Utility
Advance PCI/PnP Settings
IRQ3 [Available]
IRQ4 [Available]
IRQ5 [Available]
IRQ6 [Available]
IRQ7 [ Available ]
IRQ9 [Available]
IRQ10 [Available]
IRQ11 [Available]
IRQ12 [Available]
IRQ14 [Available]
IRQ15 [ Available ]
DMA Channel 0 [Available]
DMA Channel 1 [Available]
DMA Channel 3 [Available]
DMA Channel 5 [Available]
DMA Channel 6 [Available]
DMA Channel 7 [Available]
Reserved Memory Size [Disabled]
Select Screen
Clear NVRAM during
System Boot.
Select Item
+ - Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.XX (C) Copyright 1985-20XX, American Megatrends, Inc.
WARNING: Setting wrong values in below sections
may cause system to malfunction.
Clear NVRAM
Plug & Play O/S
PCI Latency Timer
Allocate IRQ to PCI VGA
Pallette Snooping
PCI IDE BusMaster [Enabled]
OffBoard PCI/ISA IDE Card [Auto]
[No]
[Yes]
[64]
[Yes]
[Disabled]
Main Advanced PCIPnP Boot Security Chipset Exit
LB735_BIOS_PCIPnPScreen_a
