Chapter 2 Product Overview
12 Reference Manual LittleBoard 735
Headers and Connectors
Table 2-2 describes the headers and connectors shown in Figure 2-6 on page 14 . All I/O headers use 0.100"
(2.54mm) pitch unless otherwise indicated.
Table 2-2. Header and Connector Descriptions
Jack # Name Description
BAT1 Battery Socket Battery socket for 3 volt Lithium battery
J1A,B,
C,D PC/104 bus 104-pin standard connector for PC/104
J2A,B,
C,D PC/104-Plus 120-pin, 0.079" (2mm), standard connector for PCI bus
J3 Video (VGA) 12-pin, 0.079" (2mm), header for output to a VGA compatible display
J6 IDE 40-pin standard header for the primary IDE interface
J8 Compact Flash 50-pin, 0.050" (1.27mm), socket accepts Type I or Type II Compact Flash
cards
J9 Audio In/Out 26-pin, 0.079" (2mm), header for all of the audio signals (input/output)
J10 GLAN1 8-pin, RJ45 connector for 10/100/1000BaseT Gigabit Ethernet port 1 with
magnetics
J11 Serial A 20-pin header for serial ports 1 and 2 (COM 1 & COM 2)
J12 Serial B 20-pin header for serial ports 3 and 4 (COM 3 & COM 4)
J13 Utility 2 24-pin header for mouse, SMBus, and power button
J14 USB 2 & 3 10-pin, 0.079" (2mm) header for USB2 and USB3 ports
J15 Utility 1 16-pin header for keyboard, external battery, reset switch, and speaker
J16 Parallel 26-pin header for parallel port
J17 Floppy 34-pin header for floppy disk drive interface
J18 GLAN2 8-pin, RJ45 connector for 10/100/1000BaseT Gigabit Ethernet port 2 with
magnetics
J19 Power In 7-pin, 0.156" (3.96mm), header for input power
J26 Video (LVDS) 30-pin, 0.079" (2mm), header for LVDS compatible video displays
J30 Power On 3-pin header for ATX power-on functions
J31 Memory 200-pin, 0.024" (0.60mm) socket for DDR2 SDRAM SODIMM
J32 SATA1 7-pin, 0.050" (1.27mm) standard connector for serial ATA
J33 SATA2 7-pin, 0.050" (1.27mm) standard connector for serial ATA
J34 Optional Fan 3-pin header provides +5V or +12V, tach, and ground to optional CPU fan
J35 Battery Input 2-pin, 0.049" (1.24mm) header for power from external battery
J36 TV Out 6-pin header for TV Out signals
J37 PCI Express
Mini Card (on
back of the
board; see
Figure 2-4 on
page 11
)
52-pin, 0.012" (0.30mm) standard socket for PCI Express Mini Card
functions
