LittleBoard 735 Reference Manual 21
Chapter 3 Hardware
Overview
This chapter discusses the features of the LittleBoard 735 I/O interfaces in the following order:
• Interrupt Channel Assignments
• Memory Map
• I/O Address Map
• Floppy Interface
• Parallel Interface
• Serial Interfaces
• Utility Interfaces
♦ Keyboard
♦ Mouse
♦ Battery
♦ Power Button
♦ Reset Switch
♦ Speaker
♦ SMBus
• USB Interfaces
• Audio Interface
• Video Interfaces
♦ CRT
♦ LVDS
♦ TV Out
• Power Interfaces
♦ Power In
♦ ATX Power On
♦ Power Button
• Miscellaneous
♦ Time of Day/RTC
♦ Temperature Monitoring
♦ User GPIO Interface
♦ SMBus Interface
♦ Oops! Jumper (BIOS recovery)
♦ Remote Access
♦ Watchdog Timer
♦ Optional CPU fan
