Notice Page
DISCLAIMER
ADLINK Technology, Incorporated makes no representations or warranties with respect to the contents of
this manual or of the associated ADLINK products, and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. ADLINK shall under no circumstances be liable for
incidental or consequential damages or related expenses resulting from the use of this product, even if it has
been notified of the possibility of such damages. ADLINK reserves the right to revise this publication from
time to time without obligation to notify any person of such revisions. If errors are found, please contact
ADLINK at the address shown at the bottom of this notice.
Audience
This manual provides reference only for computer design engineers, including but not limited to hardware
and software designers and applications engineers. ADLINK Technology, Inc. assumes you are qualified to
design and implement prototype computer equipment.
ii Reference Manual LittleBoard 735
TRADEMARKS
CoreModule and the Ampro logo are registered trademarks, and ADLINK, Little Board, LittleBoard,
MightyBoard, MightySystem, MilSystem, MiniModule, ReadyBoard, ReadyBox, ReadyPanel,
ReadySystem, and RuffSystem are trademarks of ADLINK Technology, Inc. All other marks are the
property of their respective companies.
REVISION HISTORY
ADLINK Technology, Incorporated
5215 Hellyer Avenue, #110
San Jose, CA 95138-1007
Tel. 408 360-0200
Fax 408 360-0222
www.adlinktech.com
© Copyright 2009, 2010, 2011, 2012 ADLINK Technology, Incorporated
Revision Reason for Change Date
00 Initial Release April/09
2.0 Revised PCI-to-ISA section in ch 4; revised +5V to be default
JP5 setting in Table 2-3 ; revised environmental specifications in
Table 2-5 ; added Table 2-7 for cooling solutions; revised
Appendix A
April/10
1010 Replaced EOL Ethernet chip; revised locations of components
and connectors; added active heatsink
Nov/10
1020 Added J47 and J48 LAN LED headers (replaced fast
RJ-45 with Gigabit RJ-45 in rev 1010); re-defined pins 1 and 3
in Table 3-13 ; changed Serial Console to Remote Access in
Ch 3 & 4; revised function definitions in Table 2-1 ; changed
description of J3 in Table 2-2 ; added fan voltage caution to
Ch 3; revised BIOS Setup procedures in Ch 4; added BIOS
Setup Utility section to Ch 4; updated index
May/12
