Chapter 4 BIOS Setup
LittleBoard 735 Reference Manual 51
• Hardware Health Configuration
♦ H/W Health Function [Disabled; Enabled]
♦ PWM Mode Setting [Fan Always On Full; Fan Disable Mode; Set duty cycle]
♦ PWM Ramp Rate [4.85 Hz; 9.62 Hz; 14.49 Hz; 24.39 Hz; 38.46 Hz; 55.56 Hz; 100 Hz; 200 Hz]
• (Appears only if “Set duty cycle” is selected) PWM Control Duty Cycle [200]
♦ CPU Temperature : XX°C/XX°F
♦ Board Temperature : XX°C/XX°F
♦ Fan Speed : XXX
♦ Vcc : X.XXX V
♦ VTR : X.XXX V
♦ VBAT : X.XXX V
• ACPI Configuration
♦ General ACPI Configuration
• Suspend mode [S1 (POS); S3 (STR); Auto]
• Repost Video on S3 Resume [No; Yes]
♦ Advanced ACPI Configuration
• ACPI Version Features [ACPI v1.0; ACPI v2.0; ACPI v3.0]
• ACPI OS Shutdown Mode [ATX; AT]
• Headless mode [Disabled; Enabled]
♦ Chipset ACPI Configuration
• APIC ACPI SCI IRQ [Disabled; Enabled]
• APM Configuration
♦ Power Management/APM [Disabled; Enabled]
♦ Video Power Down Mode [Disabled; Suspend]
♦ Hard Disk Power Down Mode [Disabled; Suspend]
♦ Suspend Time Out [Disabled; 1 Min; 2 Min; 4 Min; 8 Min; 10 Min; 20 Min; 30 Min; 40 Min;
50 Min; 60 Min]
♦ Throttle Slow Clock Ratio [87.5%; 75.0%; 62.5%; 50%; 37.5%; 25%; 12.5%]
♦ Keyboard & PS/2 Mouse [IGNORE; MONITOR]
♦ Power Button Mode [On/Off; Suspend]
♦ Advanced Resume Events Controls
• Resume On RTC Alarm [Disabled; Enabled]
- (Appears only if Enabled is selected) RTC Alarm Date (Days) [15]
- (Appears only if Enabled is selected) RTC Alarm Time [XX:XX:XX]
• MPS Configuration
♦ MPS Revision [1.1; 1.4]
• PCI Express Configuration
• Active State Power-Management [Disabled; Enabled]
